Description
Features:
1. Embedded RTOS design, Dual Core 32 bit DSP(Hi3516A).
2. H.265/H.264 dual-stream encoding.
3. Dual stream to adjust to the network flexibly.
4. Optional function: AUDIO/Alarm/TF card slot etc.
5. High quality with stable performance.
6. Free client software support for record, preview, playback.
7. Support P2P, NAT traversal and mobile monitor.
8. Support iPhone, iPad, Android Mobile.
9. Adjustable digital WDR.
10. 3D DNR, Privacy Mask, Motion Detection.
11. Open SDK support for industry customer’s secondary development.
12. Support on vif 2.4 protocol, GBT28181.
13. Support various network modes.
Description
Security cameras nowadays tend to break down quickly. But more importantly, they don’t have the capacity to produce clear images and videos. So, what can you do for your home’s safety? Where can you find a full HD IP zoom camera that can capture the best videos possible? Well, look no further than Revlight’s own motorised bullet IP camera.
Image Quality
The IR motorised lens of Revlight’s IP zoom camera allows you to adjust the camera remotely without having to even touch the device. In addition, the distance of the lens is an incredible 60 meters. The ICR infrared filter will switch depending on the time of day.
When it comes to the image output, Revlight’s IP zoom camera is a cut above the rest. The main stream can range between 1920×1080 and 1280×720, both running at 60 fps/s. In addition, the sub-stream comes in four available ranges. You also get an OSD with an impressive number of image settings. For instance, you can adjust the brightness, contrast, sharpness, and saturation. Moreover, you get several automatic options, including exposure control, gain, and aperture correction.
If you need to adjust the white balance, you can do it manually or let the camera balance things out automatically. In addition, you can also switch between manual or automatic color balancing.
Smart detection is a must with new security cameras. With that in mind, the IP zoom camera supports both intelligent defocus detection and intelligent occlusion detection.
Durability
The Revlight motorised bullet camera is quite strong. The outer casing can withstand temperatures ranging between -20℃ and +60℃. Moreover, it can handle high levels of humidity, up to 95% in fact. For a camera that only weighs 1kg, that’s quite powerful.
Connectivity
Up to 8 users can simultaneously connect to a single Revlight’s motorised bullet camera. More importantly, you can use any smart platform to connect, be it an Android or an iOS device. And if there are crafty users out there interested in some software development, the camera provides open SDK support.
Additional Functions
The Revlight motorised camera comes with plenty of optional features. For example, you can choose a camera with an audio function, or a built-in alarm system. Moreover, you can pick out a model with an additional TF card slot for a longer recording time.
Among other features, this product also has Privacy Masks and 3D DNR. In addition, it supports NAT traversal, P2P, and mobile monitoring. Plus, you also get free software support for playbacks, previews, and recording. Dual-streaming and dual-stream encoding are also an option.
Best Environments For The Motorised Bullet IP Zoom Camera
Thanks to its durable casing, the Revlight IP zoom camera is perfect for any weather condition. In other words, you will get a crystal clear image even if there’s a blizzard outside. In addition, the lens and the casing can withstand both rain and snow, and it will be some time before you will see any rust. Moreover, with its wide range of image rotation, you can use this camera if you have a large front yard. Naturally, it will work just as well with small apartments and narrow entryways.
Specification:
Model | TP-Q9B12HV |
DSP | Hi3516A |
Sensor | Starlight 2MP 1/2.8″ CMOS(Sony IMX291),color [email protected] |
Day/Night | ICR Infrared filter switching |
Lens | ¢12X8pcs |
IR LED | 2.8-12mm Motorized Zoom Lens |
IR Distance | 60M |
White Balance | Manual/Automatic |
OSD | YES |
Electronic Shutter | 1/25s~1/10000s;automatic regulation |
Video Process | H.265/H.264/MJPEG |
Image Output | Main stream: 1920×1080 1-25(60)fps/s, 1280×720 1-25(60)fps/s, |
Sub stream: 704*576, 1-25(60)fps/s, 640*480 1-25(60)fps/s,640*352, 1-25(60)fps/s, 320*240, 1-25(60)fps/s, | |
Frame Rate | 2MP @60FPS,support 1~60 FPS adjustable |
Bit Rate | 32Kb~16Mbps(Adjustable) |
Image Setting | Adjustable brightness, contrast, saturation, sharpness, white balance;AWB(automatic white balance), AGC(automatic gain), AE (automatic exposure control), AIC( automatic aperture correction) ;support privacy area occlusion;OSD superposition;image rotation: normal 90° / 270° automatic, manual or automatic color switching |
Smart coding | Supports low bit rate, low latency, ROI enhancement coding, supports 4 ROI areas |
Smart detection | Support intelligent occlusion detection and intelligent defocus detection |
Smart control | Support intelligent control, alarm opening/ shutdown, trouble shooting and intelligent noise reduction |
Protocol | IPv4, HTTP, TCP/IP, UDP, RTP, RTCP, UPNP, RTSP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, GB28181 |
Compliance | ONVIF 2.42 |
Max user access | 8 Users |
Mobile Phone | iPhone,iPad,Android Mobile |
Network Interface | 10M/100M Adaptive Ethernet port |
Working Temperature | -20 C ~ + 60 C |
Working Humidity | 0% ~ 95% |
Power Supply | POE/ DC12V |
Dimension | 285(L)×165(W)×116(D)mm |
Weight | 1.0Kg |
