Description
- 1080P HD Low illumination resolution, clear and fine images;
- Support multiple intelligent analysis;
- Support 2D/3D noise reduction, digital wide dynamic;
- Advanced H.265/H.264 video compression, Super low rate, high definition quality of image;
- Professional anti-lightning, conform to GB/T17626.5 and IEC61000-4-5;
- Support ONVIF ,access third party;
- Support various mobile monitoring(iPhone, Android);
- Provide web、CMS、center platform management software MYEYE,provide SDK development;
- Support cloud technology, easy to achieve network penetration, for in-line and alarm information pushed.
Description
What should a high-quality IP camera have? Well, that much is simple to answer. All top-tier cameras have high-resolution video capture capabilities, IR LEDs and durable lenses, wide-area coverages, a durable casing, and lots of connectivity options. In addition, they need to connect to existing security systems, as well as smart devices and regular PCs. But video coverage is just one part of modern security. A safe home will need a good IP security camera with microphone audio recording, and Revlight is here to deliver just such a product.
Lens And Video Capabilities
The Revlightsecurity IP security camera with microphone has a durable 2.8 mm fixed lens and 6 IR LED pieces. With its 30 M range, it can cover quite a bit of ground. More importantly, it comes with WDR capabilities, so you won’t have to worry about excessive light exposure during those bright, sunny days. In addition, the IR LEDs come with an ICR cut filter that alternates between recording modes depending on the time of day.
In terms of video compression, this product supports both H.264 and H.265. The frame rate is 1/25 fps, and you can easily adjust it to your liking. The mainstream image output ranges between 1920*1080 (at 25 fps) and 1280*720 (at 25fps), while the substream output stays at 704*576 at the same framerate. But most importantly, the camera supports both 2D and 3D DNR noise reduction for better interference reduction.
Network Options
Revlight’s IP camera with microphone comes with plenty of network options. Like any high-end model, the camera uses several networking protocols. More importantly, it can connect to ONVIF and allow you to capture videos on your PC or tablet at any point, with crystal-clear imagery. In addition, it can use remote client monitoring software such as MyEye to allow complete mobility.
If you’re a PC user, you will be able to use this camera with clients such as VMS and CMS or browsers like IE. On the other hand, you can hook it up to any smart device and get even more remote than before. The native XMeye app can work on both Android and iOS devices.
Durability
The Revlight IP security camera with microphone recording is one of our lightest products, weighing just 0.5 kg. However, don’t let the weight fool you — this is one tough camera! It can withstand any temperature between -10°C and +50℃, making it ideal for any weather. Moreover, it’s quite waterproof, being able to handle humidity levels up to 90%.
Other Options
There are quite a few extra benefits to this IP security camera with microphone. Thanks to its connectivity, it can support live video transmission, motion detection, JPEG image capturing, and WEB. In addition, you have full and perfect SDK support. Front-end storage, playback, and download are also available.
Specification:
Model | WIP30S-MO30 |
Sensor | 2.0M 1/2.8″ IMX291 low illumination CMOS sensor |
Day/Night | ICR |
Min.Illumination | Low LUX: 0.0001LUX @F1.2 (Color) /0.00001LUX @F1.2 (B&W) |
Lens | 2.8mm fixed lens |
IR LED | Φ8*6pcs |
IR Distance | 30M |
Noise reduction | Support 2D/3D |
Wide dynamic | Support digital |
Electronic Shutter | 1/50(60) s~ 1/10000s |
Audio | Microphone |
Alarm IO (optional) | |
Alarm I/O | 1/0 (support alarm input and video link to background) |
VIDEO | |
Compression | H.265 /H.264 |
Image output | Main stream: 1920*1080@25fps,1280*720@25fps; |
Sub-stream: 704*576@25fps; | |
Frame Rate | 1–25FPS ( Adjustable) |
Bit Rate | 100Kpbs~8Mpbs(Adjustable) |
NETWORK | |
Protocol | RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP etc. |
ONVIF | Support |
Intelligence analysis | Alarm line, alarm region, goods stranded, video block, fuzzy detection, scene change |
Other function | Support WEB,OSD,live video transmission, motion detect and IO alarm, front-end storage/playback/download, and centerreminder and image linkage, support JPEG capture; united remote client monitoring software, MYEYE,perfect SDK; |
PC Client & Browser | CMS/VMS, IE |
Mobile Phone | iPhone,iPad,Android Mobile(‘XMeye’ app) |
INTERFACE | |
Video Output | RJ45 |
LAN | 1 RJ45 10/100 Ethernet port |
GENERAL | |
Working Temperature | -10 C ~ + 50 C |
Working Humidity | 0% ~ 90% |
Power Supply | DC12V/POE |
Dimension | 106(φ)*72(H)mm |
Weight | 0.5Kg |
Package | 60pcs(59*38.5*40cm) |
