ND40 DUAL VISION THERMAL PTZ CAMERA

ND40 DUAL VISION THERMAL PTZ CAMERA

Features:

  • Front-end temperature measuring, high efficacy and accuracy, ±2°C.
  • 360° rotating PTZ, wider and further.
  • Intelligent monitoring, auto pre-alarm.
  • Clear outline, visible details.
thermal camera_1 thermal camera_2
thermal camera_3 thermal camera_4

Download Specifications

Description

Thermal Camera Sensor Technology Uncooled FPA Detector
Resolution 640*512 / 384*288 / 336*256
Spectral Band 7.5~13.5 μm
Focus 13 / 19 / 25 mm
Frame Rate 9 / 30 Hz
Visual Camera Resolution 1920*1080
Sensor 1/2.8″CMOS
Sensor Resolution 2 MP
Zoom 30 times
Focus 4.3~129.0 mm
PTZ Horizontal Angle 360°
Horizontal Speed 0°~100°/s, adjustable
Vertical Angle -90°~+90°
Vertical Speed 0°~60°/s, adjustable
Pre-set position Supported, 128 / 256 position
Cruise Scan Programmable, 6 cruise routes
Pattern Scan Programmable, each pattern > 120 seconds
Function Interface 1 way Analog video output, 1 way Audio I/O, 2 way Alarm I/O, 10/100 M RJ45
Network Protocol RTSP, RTP, TCP, UDP, UPNP, DHCP, PPPoE, ONVIF, etc.
Video Compression Standard H.264 / H.265
Temperature Measurement Full screen and partial screen temperature measurement supported.
-10°C~500°C, ±2°C/±2%
Overall Operating Temperature -40°C~70°C
Ingress Protection Grade IP66
Weight < 6 kg
Dimension 351.6*258.8*275.8 mm
Power Supply 24 VAC
Power Consumption < 45 w (Heater and illuminator excluded)
